2.6t ES26 eco Wheel Loader

ES26 Wheel Loader
Wheel Loader is a kind of earthwork construction machinery widely used in highway,railway,construction,hydropower,port,mine and other construction projects.It is mainly used for shoveling bulk materials such as soil,sand,lime,coal etc.It can also be used for slight shoveling and excavation of ores,hard soil etc.Different auxuliary devices can also be used for bulldozing,lifting,loading and unloading of other materials.
ES26ECO is a long-wheelbase loader designed by SDLG with a next generation of apperaance, and combines the
energy-saving, reliability and comfort.It has the superior stability and large breakout force, and by virtue of the
superior comperehensive prrformance, it is more suitable for mining and other heavy-duty operations.
Main sales territory: regions Europe, the United States, Russia, Ukraine, South America, Africa, southeast Asia and Australia.

Availability:

Quantity:



Inquire

Model:
ES26 ES20
Brand:
EUROSTAR OEM
Code:
84295100

ES26 Wheel loader Product Description

_{Wheel Loader is a kind of earthwork construction machinery widely used in highway,railway,construction,hydropower,port,mine and other construction projects.It is mainly used for shoveling bulk materials such as soil,sand,lime,coal etc.It can also be used for slight shoveling and excavation of ores,hard soil etc.Different auxuliary devices can also be used for bulldozing,lifting,loading and unloading of other materials.
ES26ECO is a long-wheelbase loader designed by SDLG with a next generation of apperaance, and combines the
energy-saving, reliability and comfort.It has the superior stability and large breakout force, and by virtue of the
superior comperehensive prrformance, it is more suitable for mining and other heavy-duty operations.}

_{Main sales territory: regions Europe, the United States, Russia, Ukraine, South America, Africa, southeast Asia and Australia.}

ES26 Wheel loader Product Selling Points
_{1. Operator Comfort and Safety
2. Adjustable seat, and ergonomically designed placement of instruments.
3. Comfortable A/C and heated operator environment.Two mechanical lever controls.
4. Optional pilot control.Convenient detachable cab.
5. UV resistance glass. Cigarette lighter works as electrical outlet.
6. Easy to Maintain
7. Power cut-off function prevents damage to drive components.
8. Double sealed O-rings used in Hydraulic system.
9. Stress analysis tested to strengthen weak points.
10. Sub frame and rear axle swingable by 11 degrees .
11. Front frame box structure highly torsion and damage resistant.
12. Parts, Attachments and Service to count on.
13. World class suppliers of key components.
14. Long life high performance multi valve from Zhejiang Linhai.
15. Long life highly efficient Shantui transmission and converter used.
16. Performance Reliable
17. Hydraulic system easily checked after removing front cover.
18. Easy engine access, convenient placement of key parts and fluid refill points.
19. Built for Efficiency
20 Turbo air filter removes over 90% of dust and impurities, reducing engine wear and fuel consumption extending engine service life and improving engine efficiency.
21. Radiator fan is directly engine driven and provides strong efficient cooling.
22. 38 degree angle of articulation for working in tight spaces.
23. Low fuel consumption engine that doesn't sacrifice any power.
24. Very low cycle time of 8.6 second, great for efficient for smooth strong gear changes.
25. Meets EU stage II/EPA tier 2 emission requirements.}

ES26 Wheel loader product technical parameters

Performance	Max Loading capacity(t)		2.6
	Bucket Capacity(m³)		0.8
	Lifting Height(mm)		4660
	Dumping Height(mm) (At dumping Angle at 45°)		3500
	Dumping Distance(mm)		580
	Pin Height(mm)		4040
	Max. Driving Speed(km/h)	Forward G1	6
		Forward G2	11
		Forward G3	21
		Forward G4	33
		Reverse G1	6
		Reverse G2	11
		Reverse G3	21
		Reverse G4	33
	Max. Traction(kn)		31
	Max Digging force(kn)		33
	Digging Depth(mm)		50
	Greadeability		25°
	Max. Steering Angle		35°
	Min.Turning Radius(mm)		6700
Dimensions and Weight	Overall Length(with bucket on ground)mm		5660
	Bucket Width(overall width)		2000
	Overall Height(mm)		2910
	Wheel base(mm)		2460
	Track base(mm)		1510
	Min. Ground Clearance(mm)		300
	Net weight(kg)		5000
Engine	Engine model		YUNNEI 38GBZ
	Emission Standard		National II
	Rated Power(kw)		76
	Rated Speed(r/min )		2400
	Cylinder Number		4
Transmission System	Driving Pump	Model	F1018
		Pressure(mpa)	16
		Type	Gear Pumps
	Gearbox	Type	Fixed-shaft power shift
		Gearshift	Forwardx4/Reversex4
	Driving Axle	Main Drive Type	Bevel gear reduction
		Type of Wheel side reduction	Planet gear reduction
		Reduction speed Ratio	6:37
	Tire	Model	16/70-20
		Pressure(mpa)	2.5
		Qty	4
Steering System	Type	Full Hydraulic Steering
	System Pressure(mpa)	16
	Type of Steering Pump	External tooth gear pump
	Bore size of Steering cylinder(mm)	63
	Qty(pcs)	2
Braking System	Service Brake		Disc brake
	Disc Diameter(mm)		300
	Parking Brake		Disc Brake
	Disc Diameter(mm)		160/210
Hydraylic System	Oil Pump	Model	CBG2063
		Displacement(ml/r)	63
	System Pressure(mpa)		16
	Work Distribution Valve	Model	DL15
		Type	Double Stem
	Tipping Cylinder-Inside Diameter*Bore	Ø100*445
	Lifting Cylinder-Inside Diameter*Bore	Ø90*800
Oil Capacity	Diesel Oil(L)	80
	Engine Oil(kg)	7
	Transmission oil(kg)	18
	Hydraulic oil (kg)	60
Electric	Electrical system voltage (V)	24
	Battery model	12A-80AH
	Diesel engine start type	Electric start

Factory introduction

^{Shandong Euro Star Machinery Manufacture Co., Ltd. is a professional agricultural machinery manufacturer integrating R&D, design, manufacturing, sales and service. The company products cover road transport machinery, harvest machinery, equipment for plant protection, agricultural implements and agricultural unmanned machinery.
As a professional machinery equipment manufacturer in China, the company has committed itself to provide all-round solution to global modern agricultural mechanization. The company has integrating high-end products and technologies resources around the world by upgrading of technologies, quality and service and bringing forth new ideas to create innovative products as}^{so to improve reputation and market share of eurostar in the world step by step.
The company has worked out comprehensive quality manual and quality control procedure files at all levels based on ISO9001:2000, covering product development, part purchase, production and manufacturing, quality inspection, sales and after-market service, so as to control the product quality on the whole.
Supported by comprehensive quality assurance system and developed sales and service network, the company has made leaping increase of sales in domestic market via trustful quality and outstanding service mode. Besides, Most of the company's products have passed the European CE certification.products are exported to Europe, America, Latin America, the Middle East, Asia-Pacific, CIS, Africa and more than 50 countries and regions.Our products have been recognized by all foreign customers, and we are happy to establish long-term cooperative relationships with new friends.
Aiming at satisfying the customers, we have worked hard to provide excellent and quick service to customers both at home and abroad via advanced technologies, developed products and comprehensive network so as to maximize the customer satisfaction.
In future, the company will adhere to the principle of sound business operation, continuous innovation and opening up and cooperation to create more high-end
machinery and equipment based on current ones for the society and for agriculture and contribute to global modern agriculture production.}

Agricultural machinery factory production equipment display

Service

One-stop business chain service support system
With an international service team with rich experience and excellent skill, company is committed to build a complete service guarantee system, which is professional, fast, efficient and comprehensive. Every consumer in overseas would receive a full-process service guarantee including pre-sales, on sale and after sales through the way of markets, spare parts, training service and technical support.

1) Market Service
_{^{Service Mode : Stationary Point + Circuit Service
Long-term Stationary Point Service
Short-term Circuit Technology Support Service
Service Process: Standard, High Efficient, Seasonable
Service Image: Professional, Unified}}

2) Spare Parts Service
Spare Parts Guarantee Measures: Dealer+ Spare Part Warehouse
100% original spare parts assure good quality;
Bar-code system adopted in the whole process assures accuracy and promptness;
Professional and accurate package and logistics assure safe and relieved transportation.

3) Training Service
Characteristic Training Mode: invite the technicians of dealers to factory for training, send engineers to dealers for training;
A full range of training tools, multi-language training materials, vivid training video;
Professional training teachers with rich service experience and good communication capability;
One-to-one special assignment training;
Remote online network training;

4) Technical Support
The whole process Technology support covers on sale and after-sale service.

Terms of the deal:

_{1). Delivery: 20 days for normal orders
2). Price: We have price on basis FOB Qingdao and CIF your destination for your choice
3). Payment terms for first order:
-----T/T 30% deposit and balance before shipment
-----100% L/C at sight
4). Payment for long terms cooperation of good reputation partners, we have SINOSURE insurance for our VIP clients, and we can offer credit service after we familiar with each other. We are looking for partnership for long-term business}

FAQ:

Why choose us?
1). The quality is guaranteed due to strong technical support ,first class component ,advanced production line and strict quality control system.
2). Be leading Expert in global market for more than 5 years, China Famous Export Brand recommended by CCCME (China Chamber of Commerce for Import and Export of Machinery and Electronic Products)
3). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of Eurostar' s warm reception, trustworthy and efficient professional services and persistent care.

How Shipment?
We have worked with many world famous shipping carriers and can arrange shipment to any country in the world, it can save your time and money. We can provide airfreight and ocean service.
