EPA4 & EURO V Wheel Loader

Thanks to compact dimensions and excellent control, Euro Star Wheel Loaders can work in many grounds, and tackle different problems. The hydraulic drive system makes operation more comfortable and easier. Operators can learn how to use the machines much more quickly. The individual wheel motor gives an excellent ground clearance that can make machines to be operated in restricted areas. Reliability, durability and low maintenance makes wheel loaders a good investment.
Main sales territory: regions Europe, Russia, Ukraine, South America, Africa, southeast Asia and Australia.
Availability:
Quantity:
  • H190

  • EUROSTAR OEM

  • 84295100

H series Euro V or EPA wheel loader product description
Thanks to compact dimensions and excellent control, Euro Star Wheel Loaders can work in many grounds, and tackle different problems. The hydraulic drive system makes operation more comfortable and easier. Operators can learn how to use the machines much more quickly. The individual wheel motor gives an excellent ground clearance that can make machines to be operated in restricted areas. Reliability, durability and low maintenance makes wheel loaders a good investment.
Main sales territory: regions Europe, Russia, Ukraine, South America, Africa, southeast Asia and Australia.
H series Euro V or EPA wheel loader product selling points
1) Euro V or EPA standard suitable for the Eureap and American market
2) compact dimensions and excellent control,
3)The hydraulic drive system makes operation more comfortable and easier.
4)The individual wheel motor gives an excellent ground clearance that can make machines to be operated in restricted areas.
5) Reliability, durability and low maintenance

6)Two sizes of tires available for selection

H190 Euro V or EPA wheel loader (diesel) product technical parameter

H190 Technical Data
Engine modelAOLING
3TNV88-G1
YANMAR
3TNV88-BDTYC
YANMAR
3TNV88-BWTY
Kubota D1703-M-
DI-E4B-CBH1T
Fuel typeDiesel
Cylinders3
Displacement (cc)164016421647
Emission standardsChina Off-Roda
GB2
China Off-Roda
GB3
EU Stage VEU Stage V&EPA
Tier 4 Final
Max engine output (kW)19@2200rpm28.2@3000rpm18.4@2000rpm18.2@2200rpm
Max engine torque (Nm)108@1200rpm107.7@1800rpm107.1@1200rpm96@1500rpm
Cooling systemWater
Operating voltage (V)12
Battery (Ah)70
Operating weight (kg)2000
Tipping load ,max (kg)1300
Lifting capacity,max (kg)1000
Operator's cabCanopy
Travel speed km/h0~20
Steering angle (°)45
Turn radius inside/outside (mm)1282/2790
Standard tires10.0/75-15.3
Fuel tank capacity (l)30
Hydraulic oil tank capacity (l)30
Working hydraulic flow (l/min)40
Working hydraulic pressure (bar)160
Transmission typeHydrostatic
Tires size10.0/75-15.3
400/60-15.5
Height (mm)2513
Width (mm)1160
1340
Size(mm*mm*mm)3300* 1160/1340 *2513


H series Euro V or EPA wheel loader (diesel) display

H190 (1)H190 (2)H130 Euro V or EPA wheel loader(gasoline) product technical parameter

H130 Technical data
Engine model Briggs & Stratton XR2100
Fuel type Gasoline
Cylinders 1
Displacement (cc) 420
Emission standards EU Stage V&EPA Tier 4 Final
Max engine output (kw) 10@3600rpm
Max engine torque (Nm) 28.5@3060
Cooling system Air
Operating voltage (V) 12
Battery (Ah) 20
Operating weight (kg) 500
Tipping load ,max (kg) 400
Lifting capacity,max (kg) 350
Operator's cab None
Travel speed (km/h) 0~12
Steering angle (°) 0~360
Turn radius inside/outside (mm) 0/993
Standard tires 18x9.50-8
Fuel tank capacity (l) 10
Hydraulic oil tank capacity (l) 10
Working hydraulic flow (l/min) 17.5
Working hydraulic pressure (bar) 14
Transmission type Hydrostatic
Tire size 18x9.50-8
Height (mm) 1304
Width (mm) 993

H130 Euro V or EPA wheel loader (diesel) display

H130 (1) H130 (2)

H220E Euro V or EPA wheel loader (electric) product technical parameter

 H220E Technical data
Battery Type Maintenance-free lead-
acid battery
Maintenance-free
lead-acid battery
Lithium iron
phosphate battery
Battery capacity (kwh) 19.2 26 28.8
Drive motor (kw) 30 30 30
Pump motor (kw) 28 28 28
Charging voltage (V) 110/220 110/220 110/220(380)
Charging time (h) 6~8 6~8(2)
Operating voltage (V) 12
Battery  (Ah) 45
Operating weight (kg) 2600
Tipping load ,max (kg) 1500
Lifting capacity,max (kg) 1200
Operator's cab Cab/Canopy
Travel speed (km/h) 0~20
Steering angle (°) 45
Turn radius inside/outside mm 1410/3025
Standard tires 10.0/75-15.3
Hydraulic oil tank capacity (l) 50
Working hydraulic flow (l/min) 43
Working hydraulic pressure (bar) 160
Transmission type Electric direct drive
Tires size 10.0/75-15.3
31/15.5-15
Height (mm) 2395
2400
Width (mm) 1198
1450

H220E Euro V or EPA wheel loader (electric) display

H220E (1)H220E (2)H series wheel loader supporting installation attachments display

Attachment

Wheel loader supporting installation attachments displayWheel loader supporting installation attachments display (1)

Wheel loader supporting installation Attachments display1

Wheel loader supporting installation Attachments display-1

Wheel loader supporting installation Attachments display-2

Other construction machinery products

Other construction machinery products1

downLoadImg (1)

Rubber track small excavator product display

Rubber track small excavator product display

Metal crawler small excavator product display

Metal crawler small excavator product display (1)

Wheel loader packaging and shipping display

Wheel loader Packaging and shipping display

Factory introduction:
Shandong Euro Star Machinery Manufacture Co., Ltd. is a professional Machinery and equipment manufacturer integrating R&D, design, manufacturing, sales and service. The company's products cover agricultural machinery, construction machinery, laser equipment, generator sets and so on.
As a professional machinery equipment manufacturer in China, the company has committed itself to provide all-round solution to global modern agricultural mechanization. The company has integrating high-end products and technologies resources around the world by upgrading of technologies, quality and service and bringing forth new ideas to create innovative products as so to improve reputation and market share of eurostar in the world step by step.
The company has passed the ISO9001:2015 international quality management system certification, and based on this, covering product development, part purchase, production and manufacturing, quality inspection, sales and after-market service, so as to control the product quality on the whole.
Supported by comprehensive quality assurance system and developed sales and service network, the company has made leaping increase of sales in domestic market via trustful quality and outstanding service mode. Besides, Most of the company's products have passed the European CE certification.products are exported to Europe, America, Latin America, the Middle East, Asia-Pacific, CIS, Africa and more than 80 countries and regions.Our products have been recognized by all foreign customers, and we are happy to establish long-term cooperative relationships with new friends.
Aiming at satisfying the customers, we have worked hard to provide excellent and quick service to customers both at home and abroad via advanced technologies, developed products and comprehensive network so as to maximize the customer satisfaction.
In future, the company will adhere to the principle of sound business operation, continuous innovation and opening up and cooperation to create more high-end machinery and equipment based on current ones for the society and for agriculture and contribute to global modern agriculture production.

Factory and production equipment display

loader Factory and production equipment displayService
One-stop business chain service support system
With an international service team with rich experience and excellent skill, company is committed to build a complete service guarantee system, which is professional, fast, efficient and comprehensive. Every consumer in overseas woul
d receive a full-process service guarantee including pre-sales, on sale and after sales through the way of markets, spare parts, training service and technical support.

1) Market Service
Service Mode : Stationary Point + Circuit Service
Long-term Stationary Point Service
Short-term Circuit Technology Support Service
Service Process: Standard, High Efficient, Seasonable
Service Image: Professional, Unified

2) Spare Parts Service
Spare Parts Guarantee Measures: Dealer+ Spare Part Warehouse
100% original spare parts assure good quality;
Bar-code system adopted in the whole process assures accuracy and promptness;
Professional and accurate package and logistics assure safe and relieved transportation.

3) Training Service

Characteristic Training Mode: invite the technicians of dealers to factory for training, send  engineers to dealers for training;
A full range of training tools, multi-language training materials, vivid training video;
Professional training teachers with rich service experience and good communication capability;
One-to-one special assignment training;
Remote online network training;

4) Technical Support

The whole process Technology support covers on sale and after-sale service.
Terms of the deal:
1). Delivery: 20 days for normal orders
2). Price: We have price on basis FOB Qingdao and CIF your destination for your choice
3). Payment terms for first order:
-----T/T 30% deposit and balance before shipment
-----100% L/C at sight
4). Payment for long terms cooperation of good reputation partners, we have SINOSURE insurance for our VIP clients, and we can offer credit service after we familiar with each other. We are looking for partnership for long-term business

FAQ:
Why choose us?

1). The quality is guaranteed due to strong technical support ,first class component ,advanced production line and strict quality control system.
2). Be leading Expert in global market for more than 5 years, China Famous Export Brand recommended by CCCME (China Chamber of Commerce for Import and Export of Machinery and Electronic Products)
3). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of Eurostar' s warm reception, trustworthy and efficient professional services and persistent care.

How Shipment?
We have worked with many world famous shipping carriers and can arrange shipment to any country in the world, it can save your time and money. We can provide airfreight and ocean service.

What is the machine advantage? Why I choose from you ?

A: Adopting world famous brand engine and parts, ensure long life service, all the structure parts are produced and checked by our engineers.Each machine is carefully tested before send to customer.Warranty time for 1 year or 1200 working hours.

How many units can be put in container?

A: 1-2 units can be in a 20ft container, 2-3 units can be in a 40HQ container.will be fixed with wire ropes.

Are you able to export less than 1 container of mini excavator ? And what's the wooden box's dimension and total weight ?

A:Yes ,if 1 unit or 2 units mini excavator machine could shipment by LCL, wooden box; if 4 unit or more than 4 units suggest used 20ft container. If do not have trailer, the wooden box dimension is 2.8x1.12x1.4m , about 4.3m3; if have trailer the wooden box dimension is 2.8x1.4x1.8m,about 7.54m3. Total weight about 1000kg.
