ES-150 Walking Small Reaper

ES Series Mini Self-Walking Reaper is mainly used to harvest the paddy and wheat. It could also be used to harvest the soybeans, hot pepper and reeds. It is applicable in the plain, hills, slopes, small field, etc. In addition, it is with the advantages of small volume, small weight, flexible performance and simple operation.
Main sales territory: regions Europe, the United States, Russia, Ukraine, South America, Africa, southeast Asia and Australia.
Availability:
Quantity:
ES-150 Walking Small Reaper
ES-150 Walking Small Reaper
ES-150 Walking Small Reaper
ES-150 Walking Small Reaper
ES-150 Walking Small Reaper
ES-150 Walking Small Reaper
  • ES-80 ES-100 ES-120 ES-150

  • EUROSTAR OEM

  • 8433599090

ES series mini self-walking reaper description

ES Series Mini Self-Walking Reaper is mainly used to harvest the paddy and wheat. It could also be used to harvest the soybeans, hot pepper and reeds. It is applicable in the plain, hills, slopes, small field, etc. In addition, it is with the advantages of small volume, small weight, flexible performance and simple operation.
Main sales territory: regions Europe, the United States, Russia, Ukraine, South America, Africa, southeast Asia and Australia.

ES series mini self-walking reaper product selling points
1. Except the upstanding crops, It can also reap fallen crops(lodging crops).
2.The handle can be adjusted upward or downward, with 180° rotation, more safe and suitable for different heights people.
3. It's with widen wheels, there is inner tube which are inflatable. There is differential gear, which can turn around freely.
4.This wheat/rice reaper binder adopts shaft drive, with bigger torque and high efficiency.
5. This wheat/rice reaper binder is made of high quality materials and components.
6. Small volume, compact structure, complete harvesting, low stubble, reaping&binding&putting aside at one time, more convenient and high efficiency, high quality, and long service life.

ES series mini self-walking reaper technical parameters

ES Series Mini Self- Walking Reaper
ModelES-80ES-100ES-120ES-150
Cutting Width (mm)800100012001500
Stubble Height (mm)≥50
Laying Angle (Degree)90 ± 20
Laying TypeSide Direction
Productivity (acre/h)2.0-3.02.5-43.0-5.03.5-5.5
Engine (hp)JF168 (Gasoline) 4.5hp170F (Gasoline) 5.5hp177F (Gasoline) 6hpR175 (Diesel) 8hp
Damage Rate≤1 %

ES series mini self-walking reaper display

Walking Small Cutter Windrower Swather display

ES series rear tine tiller with belt technical parameters

ES Series Rear tine tiller  (belt)
model ES680 ES680-D1 ES700-D1 ES700-D2
body size 1680*730*1000 1700*730*1150 1720*730*1150 1750*730*1150
weight(kg) 85 96 96 96
Engine 170 petrol 173 diesel 178 diesel 186 diesel
rated power(kw) 4 4.05 4.4 6.5
engine model 170P 173FS 178FS 186FS
gears  shifting walking gearbox H,0,L,R H,0,L,R H,0,L,R H,0,L,R
Tilling gearbox ditching,0, tilling ditching,0, tilling ditching,0, tilling ditching,0, tilling
transmission way Belt drive Belt drive Belt drive Belt drive
tillage depth(mm) 100-300 100-300 100-300 100-300
working width(mm) 440-720 440-720 800-1000 800-1350
ditching depthing(mm) 200-300 200-300 200-300 200-300
ditching width(mm) 250 250 250 250
tyre 350-6 solid tyre 400-8 solid tyre 400-8 solid tyre 400-8 solid tyre
standar equipment 3pcs 3 group rotary blade, ditching blade 3pcs 3 group rotary blade, ditching blade 3pcs 4 group rotary blade, ditching blade 4pcs 4group rotary blade, ditching blade
Packaging Dimension(mm) 1300×550×680 1300×550×680 1300×550×680 1400×550×680
40HQ(set)Certificates 108 108 108 98

ES series rear tine tiller with belt display

ES Series Rear Tine Tiller with Belt DisplayGW Series Rear tine tiller (gear) technical parameters

GW Series Rear tine tiller (gear)
model GW-4G01 GW-4G02 GW-4D03 GW-4D04 GW-4D05
body size 1720*730*1000 1750*730*1000 1750*730*1150 1800*730*1150 1850*730*1150
weight(kg)
87 96 96 96
Engine 170 petrol 177 petrol 173 diesel 178 diesel 186 diesel
rated power(kw) 4 5.1 4.05 4.4 6.5
engine model 170P 177P 173FS 178FS 186FS
gears
shifting
walking gearbox H,0,L,R H,0,L,R H,0,L,R H,0,L,R H,0,L,R
Tilling gearbox ditching,0, tilling ditching,0, tilling ditching,0, tilling ditching,0, tilling ditching,0, tilling
transmission way gear gear gear gear gear
tillage depth(mm) 100-300 100-300 100-300 100-300 100-300
working width(mm) 440-720 800-1000 440-720 800-1000 800-1350
ditching depthing(mm) 200-300 200-300 200-300 200-300 200-300
ditching width(mm) 250 250 250 250 250
tyre 350-6 solid tyre 400-8 solid tyre 400-8 solid tyre 400-8 solid tyre 400-8 solid tyre
standar equipment 3pcs 3 group rotary blade, ditching blade 3pcs 4group rotary blade, ditching blade 3pcs 3 group rotary blade, ditching blade 3pcs 4 group rotary blade, ditching blade 4pcs 4group rotary blade, ditching blade
Packaging Dimension(mm) 1300×550×680 1300×550×680 1300×550×680 1300×550×680 1400×550×680
40HQ(set)Certificates 108 108 108 108 98

GW Series Rear tine tiller (gear) Display

GW Series Rear tine tiller (gear) DisplayES Series tiller technical parameters

ES Series tiller
model ES-1000 ES-1100A ES-1000D ES-1100B ES-1100C ES-720
body size 1630×1000×1020 1750×1100×940 1630×1000×1020 1750×1100×940 1750×1100×940 1680×660×930
weight(kg) 70 83 85 115 135 75+40
Engine 170 petrol 177 petrol 173 diesel 178 diesel 186 diesel 178 diesel
rated power(kw) 4 5.1 4.05 4.4 6.5 4.4
engine model YH170F YH177F YH173FS YH178FS YH186FS zongshen
gears shifting 2,0,1,-1 2,0,1,-1 2,0,1,-1 2,0,1,-1 2,0,1,-1 3,2,1,
0,-1,-2
Driving model gear gear gear gear gear gear
Tilling depth(mm) ≥100mm ≥100mm ≥100mm 100-300 100-300 150-250
Tilling scope(mm) 1000 800-1000 1000 800-1000 800-1350 600
tyre 350-6 solid tyre 400-8 solid tyre 350-6 solid tyre 400-8 solid tyre 400-8 solid tyre 400-8 solid tyre
standar equipment 3pcs 3 group rotary blade 3+1 blades 3pcs 4 group rotary blade 3+1 blades 3+1 blades 10pcs 3 group rotary blade
Packaging Dimension(mm) 850×730×700 1050*570*780 850×730×700 1050*570*780 1050*570*780 850×720×600+
720×550×450
40HQ(set)Certificates 144 108 144 108 108 112

ES Series Tiller Display

S Series tiller displayRear Tine Tiller packing and shipping link display
packing and shipping link display

Factory introduction
Shandong Euro Star Machinery Manufacture Co., Ltd. is a professional Machinery and equipment manufacturer integrating R&D, design, manufacturing, sales and service. The company's products cover agricultural machinery, construction machinery, laser equipment, generator sets and so on.
As a professional machinery equipment manufacturer in China, the company has committed itself to provide all-round solution to global modern agricultural mechanization. The company has integrating high-end products and technologies resources around the world by upgrading of technologies, quality and service and bringing forth new ideas to create innovative products as so to improve reputation and market share of eurostar in the world step by step.
The company has passed the ISO9001:2015 international quality management system certification, and based on this, covering product development, part purchase, production and manufacturing, quality inspection, sales and after-market service, so as to control the product quality on the whole.
Supported by comprehensive quality assurance system and developed sales and service network, the company has made leaping increase of sales in do
mestic market via trustful quality and outstanding service mode. Besides, Most of the company's products have passed the European CE certification.products are exported to Europe, America, Latin America, the Middle East, Asia-Pacific, CIS, Africa and more than 80 countries and regions.Our products have been recognized by all foreign customers, and we are happy to establish long-term cooperative relationships with new friends.
Aiming at satisfying the customers, we have worked hard to provide excellent and quick service to customers both at home and abroad via advanced technologies, developed products and comprehensive network so as to maximize the customer satisfaction.
In future, the company will adhere to the principle of sound business operation, continuous innovation and opening up and cooperation to create more high-end machinery and equipment based on current ones for the society and for agriculture and contribute to global modern agriculture production.

Tractor production workshop displayAgricultural machinery factory production equipment display

Service
One-stop business chain service support system
With an international service team with rich experience and excellent skill, company is committed to build a complete service guarantee system, which is professional, fast, efficient and comprehensive. Every consumer in overseas would receive a full-process service guarantee including pre-sales, on sale and after sales through the way of markets, spare parts, training service and technical support.

1) Market service

Service Mode : Stationary Point + Circuit Service

Long-term Stationary Point Service
Short-term Circuit Technology Support Service
Service Process: Standard, High Efficient, Seasonable
Service Image: Professional, Unified

2) Spare parts service
Spare Parts Guarantee Measures: Dealer+ Spare Part Warehouse
100% original spare parts assure good quality;
Bar-code system adopted in the whole process assures accuracy and promptness;
Professional and accurate package and logistics assure safe and relieved transportation.

3) Training service
Characteristic Training Mode: invite the technicians of dealers to factory for training, send  engineers to dealers for training;
A full range of training tools, multi-language training materials, vivid training video;
Professional training teachers with rich service experience and good communication capability;
One-to-one special assignment training;
Remote online network training;

4) Technical support
The whole process Technology support covers on sale and after-sale service.
Terms of the deal:
1). Delivery: 20 days for normal orders
2). Price: We have price on basis FOB Qingdao and CIF your destination for your choice
3). Payment terms for first order:
-----T/T 30% deposit and balance before shipment
-----100% L/C at sight
4). Payment for long terms cooperation of good reputation partners, we have SINOSURE insurance for our VIP clients, and we can offer credit service after we familiar with each other. We are looking for partnership for long-term business

FAQ:
Why choose us?
1). The quality is guaranteed due to strong technical support ,first class component ,advanced production line and strict quality control system.
2). Be leading Expert in global market for more than 5 years, China Famous Export Brand recommended by CCCME (China Chamber of Commerce for Import and Export of Machinery and Electronic Products)
3). One-stop service with a larg
e spare parts warehouse and professional service team .No matter where you are, you are guaranteed of Eurostar' s warm reception, trustworthy and efficient professional services and persistent care.
How shipment?
We have worked with many world famous shipping carriers and can arrange shipment to any country in the world, it can save your time and money. We can provide airfreight and ocean service.

What is the machine advantage? Why I choose from you ?

A: Adopting world famous brand engine and parts, ensure long life service, all the structure parts are produced and checked by our engineers.Each machine is carefully tested before send to customer.Warranty time for 1 year or 1200 working hours.

How many units can be put in container?

A: 1-2 units can be in a 20ft container, 2-3 units can be in a 40HQ container.will be fixed with wire ropes.

Are you able to export less than 1 container of mini excavator ? And what's the wooden box's dimension and total weight ?

A:Yes ,if 1 unit or 2 units mini excavator machine could shipment by LCL, wooden box; if 4 unit or more than 4 units suggest used 20ft container. If do not have trailer, the wooden box dimension is 2.8x1.12x1.4m , about 4.3m3; if have trailer the wooden box dimension is 2.8x1.4x1.8m,about 7.54m3. Total weight about 1000kg.
